Sensaphone IMS-4010E-INT Node with Dry Contact Inputs for 220VAC
Original price was: $512.10.$102.42Current price is: $102.42.
Node w/Dry Contact Inputs for 220VAC
Features:
- Allows users to monitor up to 8 dry contact inputs
- Battery backup in the event of a power failure
- Can be set to alarm on power failure
It is ideal for monitoring the alarm outputs of devices such as a UPS, power distribution unit, fire alarm panel, automatic transfer switch or security system. The unit uses four AA rechargeable NiMH batteries (included) for power backup in the event of a power failure. Both main power and battery charge are monitored and can be programmed to trip alarms as well. The unit comes in a black plastic enclosure with tabs for wall mounting.
| Number of Inputs | 8 |
| Input Type | Dry Contact, Normally Open or Normally Closed (configurable for each input) |
| Internal Monitoring | AC Power, Backup Battery |
| Ethernet | 10/100 Base-T, 10/100Mbps |
| Serial Port | 9600Bps for network configuration |
| Local Indicators | Power LED, Ethernet LEDs |
| Operating Temperature | 32° to 122°F (0° to 50°C) |
| Operating Humidity | 5 – 90% RH non-condensing |
| Power Consumption | 2.5W |
| Power Requirements | 90-260VAC 50/60Hz 300mA (min) Multiplug Power Supply |
| Battery Backup | Four AA NiMH Rechargeable Battery, 2000mAHr or higher (included) |
| Dimensions | 7.3 x 5.5 x 1.5″ |
| Weight | 2lbs |
Related products
-
Automation & Control
Sensaphone FGD-0105 10K Type Immersion Temperature Sensor
