Wichard U-Bolt Pad Eye – 8mm Diameter – 5/16″ – 100mm Length – 3-15/16″

Wichard U-Bolt Pad Eye – 8mm Diameter – 5/16″ – 100mm Length – 3-15/16″ Product Description

U-Bolt Pad Eye – 8mm Diameter – 5/16″ – 100mm Length – 3-15/16″

Features:

• Entirely drop forged product with high-quality stainless steel
• Outstanding working and breaking loads
• For any fastening applications (shrouds, lifelines, blocks…)
• Delivered with bolts and counter-plate
• Max tightening torque: 18 Nm

Applications:

• Various fastening applications: shrouds, lifelines, blocks…

Specifications:

• Materials: 316L stainless steel grade
• Working load: (lb) 5290 / (kg) 2400
• Breaking load: (lb) 10580 / (kg) 4800
• Weight: (lb) 0.28 / (g) 127

Dimensions:

• A: (inch) 1 27/64″ / (mm) 36
• B: (inch) 1 3/16″ / (mm) 30
• C: (inch) 2 23/64″ / (mm) 60
• D diameter: (inch) 5/16″ / (mm) 8
• Length: (inch) 3 15/16″ / (mm) 100

Caption:

• Working Load (WL): For nautical applications
• Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5

*Sold as an Individual

Frequently Asked Questions (FAQ) About Wichard U-Bolt Pad Eye – 8mm Diameter – 5/16″ – 100mm Length – 3-15/16″

Who is the Wichard Marine?

Who is the Wichard Marine?

For more than 100 years Wichard’s main mission has been to provide customers with quality products that ensure both safety and optimum performance for their sports and professional activities. Choosing a Wichard product means above all choosing a quality product that will ensure safety and performance during your voyages.
