Turning Insert: CCMT32.52ENSM CTCP125P, Carbide

Original price was: $11.39.Current price is: $3.42.

Add to Wishlist
Compare
26280743_A

Product Specifications

ANSI Insert Code CCMT32.52
ISO Insert Code CCMT09T308
Relief Angle 7
Insert Style CCMT
Corner Radius (Decimal Inch) 0.0315
Included Angle 80
Manufacturer Grade CTCP125P
Coating/Finish TiCN; TiN; Al2O3
Wiper Edge No
Insert Hand Neutral
Insert Thickness (Decimal Inch) 0.1563
Series CCMT
Inscribed Circle (Decimal Inch) 0.3748
Insert Material Carbide
Insert Shape C – Diamond (Rhombic) 80-Deg
Side Clearance Positive
Number Of Cutting Edges 2
Insert Shape Code C
Hole Diameter (Decimal Inch) 0.1732
Maximum Depth of Cut (Decimal Inch) 0.3819
Insert Holding Method Screw
Clearance Code C
Tolerance Code M
Coating Process CVD
Rake Positive
Primary Workpiece Material Cast Iron; Steel
Primary Workpiece Material Code P; K
Secondary Workpiece Material Stainless Steel
Secondary Workpiece Material Code M
Iso Code CCMT 09T308EN-SM CTCP125-P
Chip Breaker SM
ANSI Size Code 32.52
ISO Size Code 09T308
UNSPSC Code 23242105
Insert Size Code 32.52
