Schlage J54CNA630 Corona Entry Lock Knob, C Keyway, Satin Stainless Steel, 16255 Latch

Schlage J54CNA630 Corona Entry Lock Knob, C Keyway, Satin Stainless Steel, 16255 Latch

Schlage Residential – J Series J54CNA630 Entry Lock Corona Knob with C Keyway offers a perfect blend of security and style for any home. This durable entry lock is constructed from stainless steel and features a sleek satin finish, ensuring it stands up to daily use while maintaining an elegant appearance. Designed for ease of installation, the J54CNA630 includes all necessary mounting hardware and is compatible with standard door preparations, accommodating door thicknesses from 1-3/8″ to 1-3/4″. This mechanical lockset operates with a keyed function, allowing entry through a rotating cylinder from the outside and a turn button from the inside. The reversible handing makes it versatile for various door orientations. The lockset is ANSI/BHMA A156.36 Grade 3 certified, demonstrating its reliability and security. With a lifetime mechanical warranty and a 5-year finish warranty, you can trust in the quality and durability of this product. The adjustable backset of 2-3/8″ or 2-3/4″ ensures a perfect fit for most installations, while the 2-1/8″ crossbore size simplifies the fitting process. The round rose design complements the Corona knob, making it an attractive choice for any residential setting.

Entry Lock Corona Knob with C Keyway 16255 Latch and 10101 Strike Satin Stainless Steel Finish

Perfect for any home, with a 25-year mechanical warranty, Dexter products are built to last. Dexter by Schlage J Series Products are backed by a lifetime mechanical warranty and 5 year finish and made by a name you can trust. These durable grade 3 products are easy to install and fit standard door preps. Focused on elegant, sleek designs and the ability to be keyed to other Schlage locks for one key-convenience, customers know they are getting the best in affordable lock security. Dexter also focuses on the ease of installation, with products that often have a one-tool installation to make the process as seamless as possible. Though the installation is easy, Dexter products are dependable in their security.

• Easy installation
• Fits all standard door preparations
• Lifetime mechanical warranty and 5-year finish warranty
• Handleset deadbolt can thrown or retracted by key from outside or by inside turn unit
• Can be rekeyed to match existing locks or other locks purchased
• Includes All Mounting Hardware for Easy Installation
• Reversible Handing
• Entry (Keyed) Function – Locked by Key and Rotating Cylinder from Outside; Unlocked by Key on Outside or from Turn Button on inside
• ANSI/BHMA A156.36 Grade 3
• Lifetime Mechanical & 5 Year Finish Warranty
• Use with 1-3/8 in. to 1-3/4 in. door
• Guaranteed to fit on standard pre-drilled doors
• Knob design pairs well with minimalist, geometric designs
• Always unlocked for ease of entry
• Easy installation with screwdriver
• Self-aligning screw holes make installation easy and hassle-free
• Universal latches slide easily into place and require no tools or manual adjustments
• Certified Commercial grade 3

Attributes

Ship via: Can Ship UPS

Alternate Codes: 043156742851, 133095, DEXJ54CNA630, J54CNA630

Backset: Adjustable 2-3/8″ or 2-3/4″ Backset

Category: Mechanical Residential Locksets

Crossbore Size: 2-1/8″ Bore

Cylinder Included: Yes

Cylinder Type: 5 Pin Cylinder-KIK

Design: Corona

Dimension: 2″ Knob Diameter and 2-3/4″ Projection with 2-5/8″ Diameter Rose

Door Application: Residential Locks

Door Bore Size: 2-1/8″

Door Range: 1-3/8″ to 1-3/4″

Door Thickness: 1-3/8″ to 1-3/4″

Door Thickness Max: 1-3/4″

Door Thickness Min: 1-3/8″

Faceplate Height: 2-1/4″

Faceplate Width: 1″

Finish: Satin Stainless Steel

Finish Code: 630

Finish Color: Satin Stainless Steel

Finish Description: Satin Stainless Steel

Function: Entry

Grade: Grade 3

Handing: Reversible

Hazardous Material: NO

Keying: Keyed Alike

Keyway: Schlage C Keyway

Knob Design: Schlage Corona

Knob/ Lever Design: Corona

Knob/ Lever Style: Knob

Latch Bolt Face Type: Drive-In, Round Corner, Square Corner

Latch Bolt Faceplate Size: 2-1/4″ x 1″

Latch Bolt Throw: 1/2″

Latch Bolt Type: Deadlatch

Latch Faceplate Dimension: Square and Round Corner 1″ x 2-1/4″ Faceplate or 1″ Collar

Latchbolt Type: Deadlatch

Lever Knob Design: Corona Knob

Lock Category: Cylindrical Lock

Manufacturer Warranty: Limited Lifetime Mechanical and 5 Year Finish Warranty

Material: Stainless Steel

No Of Inners: 1

No Of Pins: 5 Pin Cylinder

Order_ Qty: 1

PO date: 2024-09-03

Restricted Keyway: No

Rose Escutcheon Design: Round Rose

Rose/ Escutcheon Style: Rose

Series: J Series

Strike: Radius Full Lip Strike

Strike Dimension: 2-1/4″ x 1-5/8″ x 1-1/8″ Lip

Strike Size: 2-1/4″ x 1-5/8″

Strike Style: Radius Corner

Strike Type: Full Lip Strike

Subcategory: Residential Door Knobs

Subtype: Tubular Lock

Supplier: Schlage

Type: LOCK SETS
