Sargent 28-7U15 LL 10 Cylindrical Lock

Sargent 28-7U15 LL 10 Cylindrical Lock
A key-in-lever lock designed for standard duty commercial interior and exterior applications in public buildings, medical offices, hotels/motels and government facilities. Exceeds ANSI/BHMA A156.2 standards for cycling and durability

Attributes

Ship via: Can Ship UPS

Ansi Function: F75 – Passage

Ansi Function Description: Passage

Baa Qualified: Yes

Backset: 2-3/4″ Backset

Bolt Protection: 1/2″

Bore Hole Diameter: 2-1/8″

Country of Origin: Usa

Cylinder Type: Non-Keyed

Cylinders Present: Non-Keyed

Design: L Lever and L Rose

Door Thickness: 1-3/8″ – 1-3/4″

Dust Box: None

Finish: 612/US10

Finish Description: Satin Bronze Clear Coated

Fire Rated: No

Function: 15-Passage

Function Family: Passage

Grade: Grade 2

Hand: Not Handed

Latch Backset Dim: 2-3/4″

Latch Bore Diameter: 7/8″

Latch Number: 07-2428

Latch Type: Spring Latch (Unguarded)

Lever Knob: Lever

Lever Knob Design: L – Lever

Lever Knob Design Family: Straight Return Lever

Lever Knob Design Name: L

Limited Warranty: 5 Years

Lock Face Size: 2-1/4″ x 1-1/8″

Manufacturer Function: Passage

Manufacturer Function Description: Operated by latch either lever.

Maximum Door Thickness: 1-3/4″

Minimum Door Thickness: 1-3/4″

Projection: 2-1/2″

Rose Escutcheon: Rose

Rose Escutcheon Design: L – Rose

Rose Escutcheon Dimensions: 3-3/8″

Screws: Combination

Series: 7-Line Bored Lever Locks

Strike: ASA Strike

Strike Dimensions: 1-1/4″ x 4-7/8″

Strike Height: 4-7/8″

Strike Number: 808

Strike Type: ASA

Strike Width: 1-1/4″

Structure Function: U15

Structure Latch Number: 194493

Structure Outside Finish: US10

Structure Outside Trim: L

Structure Series: 7Line

Structure Strike Number: 808

Subtype: Cylindrical Lock

Type: Locks, Cylinders, Cores, Keyblanks
