Poly-Planar 4CH, 120W, Audio Amplifier w/Volume Control

Poly-Planar 4CH, 120W, Audio Amplifier w/Volume Control Product Description

4 Channel,120watt, Audio Amplifier with volume control
Part Number: ME60
The ME60 is a four channel 120 Watts RMS audio amplifier of delivering up to 30W RMS per channel. It has a compact, water resistant design that allows for flexible mounting possibilities, and makes it simple to expand the audio system capabilities for any installation.
Uses:

• To add additional loudspeakers to a current audio system
• To provide amplification for a separate audio zone
• As a stand-alone system amplifier for any audio source
• To power standard speakers or speakers and subwoofer

Features

• Powers up to (8) 4ohm speakers
• Internal distortion limiting circuits
• Dedicated gain level control
• External volume control with ON/OFF switch included
• Water resistant design for marine use
• Rear channels switchable from full range to powered sub out.

Specifications

• Speaker Impedance:2-8 ohm
• Output Power (4 ohm load) 20 Watts RMS per Channel (50W Peak):(2 ohm load) 30 Watts RMS per Channel (70W Peak)
• Frequency Response:20Hz-40kHz
• Low Pass Crossover:18 – 245 Hz
• Operating Voltage:13.8V DC (10V-16V)
• Maximum Current Draw (full power):8-10amps
• Dimensions (approx. w x h x d):175mm x 115mm x 35mm 6.9″ x 4.5″ x 1.4″
• Installation Clearance:250mm free space top/sides
• Weight:1.65lbs
• Volume Control Cable Length:290cm/114″
  It has a compact waterproof design that enables flexible installation possibilities and makes it easy to expand the audio system functions for any installation. to …


  Poly-Planar 4CH, 120W, Audio Amplifier w/Volume ControlRelated Products

  Marine Audio Marine Grade RCA Cable – 13′ (4M)

  Frequently Asked Questions (FAQ) About Poly-Planar 4CH, 120W, Audio Amplifier w/Volume Control

  Who is the Poly-Planar?
  How to describe Poly-Planar 4CH, 120W, Audio Amplifier w/Volume Control?
  What is the waterproof rating of the product?
  What is the watts of the product?
  Is this product bridgeable?

  Who is the Poly-Planar?

  PolyPlanar is the world’s best known designer and manufacturer of waterproof and corrosion proof audio systems and outdoor speakers for marine, outdoor, deck, pool, patio, and boating applications. PolyPlanar is the Waterproof Marine Audio System with the Concert Hall Sound.Keep in mind; Poly-Planar takes as much pride in their speakers as you take in your boat, deck, or pool.
