Kyocera – CPMH321 Y Grade TN620 Cermet Turning Insert

Original price was: $12.09.Current price is: $3.63.

Add to Wishlist
Compare
96205588_A

Features and Benefits

Cermet is comprised of ceramic and metal and can be used at higher speeds than coated carbides. It is commonly used on cast iron, steel, stainless steel and nonferrous materials.

Product Specifications
Insert Style CPMH
Insert Size 321
Material Cermet
Inscribed Circle (Inch) 3/8
Thickness (Inch) 1/8
Corner Radius (Inch) 1/64
Manufacturer’s Grade TN620
Coating TiCN
Chip Breaker Y
Hole Diameter (Decimal Inch) 0.1772
ISO Number CPMH090304R-Y
Rake Positive
Relief Angle 11
Coating Process Uncoated
Manufacturers Catalog Number CPMH321RY TN620
Primary Workpiece Material P
Included Angle 80
Insert Hand Right Hand
Series CPMH
Insert Holding Method Screw or Clamp
Multi Use Application Boring, Internal Facing
MultiUseTool Yes
Shape Diamond
