FLIR M300C Stabilized Visible IP Camera

FLIR M300C Stabilized Visible IP Camera Product Description

M300 Series cameras are available single or dual payload configurations. Dual payload models feature a 640 thermal camera core plus a high-definition lowlight visible camera with 30x optical zoom. Single payload thermal M300 series cameras are available with a 320 or 640 resolution thermal camera or a single high-definition lowlight visible camera with 30x optical zoom.

FLIR Systems E70605 Attributes

• Type: Stabilized Pan/ Tilt/ Zoom
• Display Type: No Display
• Operating Temperature (Deg F): -13 To 131 Degree Fahrenheit
• Horizontal Viewing Angle: 64 Degree
• Vertical Viewing Angle: 36 Degree
• Used To: Detect Objects In Darkness/ Fog/ Glare
• Color: White
• Weatherproof: Yes
• With Remote Control: No

FLIR Systems E70605 Features & Benefits

• Active Gyro-Stabilization And Continuous 360 Degree Panning Offer Complete Awareness In Any Direction
• Patented FLIR Color Thermal Vision Blends Thermal And Visible Imagery For Enhanced Awareness
• Designed To Withstand Punishing Weather And High Seas With Robust Shock Protection And An IP56-Rated Housing
• Automatic Window Heaters For Clearing Ice
• Video Over IP And Ethernet Control For Networking With MFDs And Security Systems
• Analog Video And HD-SDI Broadcast-Quality Video Output
• M300 Series Offers Single-Sensor Visible And Thermal Models, As Well As Dual-Sensor Multispectral Systems
• Exceptional Connectivity With Navigation Displays From Leading Marine Electronic Brands And Security Systems
• Limited 2 Year Warranty

FLIR Systems E70605 Technical Bulletins

• M300C-Datasheet-US.pdf

M300C Stabilzed Visible IP Camera

Combining  a  high-performance  visible  marine  camera  with  long-range optical zoom capability, the M300C offers positive target  identification  for  law  enforcement,  commercial, and  recreational applications. Advanced gyro-stabilization provides steady imaging in rough sea conditions and allows the M300C to monitor targets or hazards over long distances continuously.  Exceptional low light performance from the M300C gives captains enhanced awareness once the sun dips below the horizon.

HIGH DEFINITION NAVIGATION

Low light HD visible imaging sensor and long-range zoom offer enhanced target identification.

• Better than binoculars, the M300C with 30x optical zoom and image stabilization delivers superior long-range imaging and positive target identification
• Ultra-low light camera technology provides visible imagery in the most challenging lighting conditions
• Overlay AIS targets, chart objects, and waypoints in real time when combined with Raymarine Axiom and award-winning ClearCruise™ augmented reality technology

A STEADY VIEW IN ROUGH SEAS

Stable viewing in heavy seas keeps eyes on-target.

• Two-axis mechanical stabilization virtually eliminates the effects of pitch, heave, and yaw
• Electronic stabilization minimizes low frequency rumble and vibration
• Integrated AHRS (Attitude Heading Reference Sensor)
• Horizontal stabilization automatically keeps the camera on scene as you maneuver

SEAMLESS INTEGRATION

Exceptional connectivity with navigation and security systems.

• Optional joystick control unit and integration with multifunction navigation displays (JCU2)
• ONVIF-compliant for PTZ security camera functionality
• H.264 IP video stream and HD-SDI lossless digital video interface
• Composite analog video (SD) for integration into legacy displays

Included:

• M300 Camera
• Camera base-seal
• Camera gasket
• RayNet-to-RJ45 adaptor cable 120 mm (4.72 in.)
• Right-angled RayNet-to-RayNet cable 3 m (9.8 ft.)
• Right-angled HD-SDI video cable (with BNC connectors) 3 m (9.8 ft.)
• Right-angled power/NMEA 0183/video cable 3 m (9.8 ft.)
• Mounting riser
• 3 x camera fixings: nuts, dome nuts, spring and flat washers, threaded studs
• 2 x self-adhesive decals (for ball-down mounting only)
• Documentation pack

HD camera or JCU FLIR M300C single payload model: M300C combines a high-performance visible navigation camera and remote optical zoom function, M300C provides reliable target recognition for law enforcement, commercial and entertainment applications. The advanced gyroscope stabilization function can provide stable imaging effects in turbulent sea conditions, and allows the M300C to continuously monitor long-distance targets or dangers. Once the sun falls below the horizon, the M300C will have excellent low-light performance, thereby enhancing the captain’s awareness. The low-light high-definition visible light imaging sensor and long-distance zoom can enhance target recognition capabilities. Excellent connectivity to navigation and safety systems.
