Blue Sea 1832 M2 DC Ammeter

Blue Sea 1832 M2 DC Ammeter Product Description

M2 DC Ammeter
Monitors DC Amperage with large, bright display. Accurately measure and monitor the amperage of your DC system. (measures 2 circuits) Supports programmable shunt ratios.
Features:

• Auto-dimming, bright OLED display is easy to read
• Easy to adjust
• 92dB alarm on all models
• Isolated MOSFET relay

Specifications:

• Meter: Current
• Function: to 5000A (500A with included shunt)
• Alarms: High Current
• Display Size: 55mm x 28mm
• Input Voltage: 7-70V DC
• Maximum Power Consumption: 1.00Watt
• Minimum Power Consumption: 0.3 Watt

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The M2 OLED digital monitor measures basic electrical system parameters through adjustable alarms and an automatically dimming display in a compact housing. The gasket will form a waterproof seal on the surface of the device. The M2 monitor includes a MOSFET external circuit relay (ECR), which can be used to control an external circuit based on any value measured by M2. M2 external circuit relay and internal alarm function are independent and independent.

Frequently Asked Questions (FAQ) About Blue Sea 1832 M2 DC Ammeter

Who is the Blue Sea Systems?
How to describe Blue Sea 1832 M2 DC Ammeter?

Who is the Blue Sea Systems?

Blue Sea Systems is committed to the improvement of marine electrical products and systems, such as panel systems, circuit breakers, connectors, and insulators.Blue Sea wants to satisfy their distributors, dealers and ultimately the retail customer by designing and manufacturing electrical products engineered to withstand the harsh marine environment.
