Attwood Stainless Steel Thru-Hull Short Straight Barbed – 1″ Inner Diameter

Attwood Stainless Steel Thru-Hull Short Straight Barbed – 1″ Inner Diameter Product Description

Polish your image with these beautiful, durable stainless steel fittings. Each Thru-Hull and Scupper Valve is available with a new silicone gasket.

Attwood Marine 665423 Attributes

• Type: Barbed Thru-Hulls
• Hose Diameter: 1 Inch
• Color: Silver
• Material: Stainless Steel
• Quantity: Single

Attwood Marine 665423 Features & Benefits

• Cast From Certified Enhanced #316 Stainless Steel Allow For Strength
• Lifetime Corrosion-Resistance
• Polish All Visible Areas To A Mirror Finish, Then Each Part Through A Passivation For Additional Protection
• Thick Steel Sidewalls Withstand Continual Stress And Hose Flexing
• Gasket Is Dimensionally Stable–Will Not Deteriorate Or Shrink Over Time
• Excellent Resistance To UV And Weather-Aging
• Watertight, Fool-Proof, One-Piece Seal
• Eliminates The Need To Form And Apply Sealant Or Caulk
• No More Chemicals, Solvent-Soaked Rags, Or Cleanup
• Limited Lifetime Warranty

Attwood Marine 665423 Installation Instructions

• 069373g ssthruhullscupper.pdf

Attwood Marine 665423 Warranties

• Attwood Warranty 2009.pdf

Stainless Steel Thru-Hull Short Straight Barbed – 1″ Inner Diameter

Polish your image with these beautiful, durable stainless steel fittings. Why specify plastic parts when these fittings will last the life of the boat?

Rugged Stainless Construction:

• Cast from certified Enhanced 316 Stainless Steel alloy for strength and lifetime corrosion-resistance
• All visible areas are polished to a mirror finish, then passivate each part for additional protection
• Thick steel sidewalls withstand continual stress and hose flexing

Faster, Simpler Installation:

• Each Thru-Hull is available with a new silicone gasket
• A channel under the flange holds a bead of sealant, making it easier to apply a trouble-free seal
• All models have wrench flats or an end notch to hold as a gripping surface; one installer can tighten all connections from inside the hull
• The barbed tail ends provide plenty of room to hold multiple clamps

Stainless Steel Straight Thru-Hulls, Barbed

• Short Thread is a more compact size, which allows installation near corners and in confined areas

Specifications:

• Hose size: (inch) 1″ inner diameter
• Flange Diameter: (inch) 2-1/4″
• Thread O.D. (outside diameter): (inch) 1-3/8″
• Thread Length: (inch) 1-1/8″
• Barb Length: (inch) 1″
• Total Length: (inch) 2-1/2″
• Install Hole Saw Size: (inch) 1-1/2″
• Thread NPSM: (inch) 1″
• Max Hull Thickness: (inch) 5/8″

*Stainless Steel Thru-Hull Connectors are designed for installation above the water line only

Frequently Asked Questions (FAQ) About Attwood Stainless Steel Thru-Hull Short Straight Barbed – 1″ Inner Diameter

Who is the Attwood Marine?
What is the type of the product?
What is the material of Attwood Stainless Steel Thru-Hull Short Straight Barbed – 1″ Inner Diameter?
What’s the color of Attwood Stainless Steel Thru-Hull Short Straight Barbed – 1″ Inner Diameter?

Who is the Attwood Marine?

For more than 100 years Attwood has been proud to serve the parts and accessory needs of the marine industry. Attwood has been partnered with you to design, manufacture, test, and distribute a complete line of products that have been a part of your tradition.The people at Attwood are proud to be more than just a “middle man” that buys and sells components.
